Dennis Javelin—S.Cam Braking System Rear



To return to our home page click on one the buses above and they will take you there.



To go to another section click on the link below.



Front Axle Rear Axle Braking System Change Speed Cooling System Electrical System Engine Controls Engine and Mounting Exhaust System Fuel System & Gearbox Hydraulic System Propshaft Steering Suspension



OE Part No   Our Part No   Part Description                                           Chassis     Price



605208       274746        Stop Light Switch

605293       KW2996/1      Single Check Valve

609010       280375        Relay Valve

609011       274997        Quick Release Valve

610582-A     295476        Low Pressure Switch

611463-6                   Brake Drum — Front                                         Mk1

611529       KY1916/1      Footbrake Valve Assembly

611529-1     295579        Footbrake Valve

611970       VPS48HI       Multi Circuit Protection Valve

612049       277148        Pressure Protection Valve

612503       KW2996/1      Single Check Valve

612527-2                   Brake Shoe Retaining Spring                                Mk1

613553       KZ1291/2      Condensor

614170-1                   C Spring

650057       277486        D2 Governor Valve

650060       KX1058/1      Diff Protection Valve

650209       VPS48AI       Multi Circuit Protection Valve

650418-39                  Bush — Brake Camshaft                                      Mk1

650711-8                   Brake Drum — Rear                                          Mk1

651017-3                   O Ring — Brake Camshaft                                    Mk1

651166-8                   Pivot Pin                                                  Mk1

651166-9                   Anchor Pin — Brake Shoe                                    Mk1

651166-13                  O Ring Sleeve — Brake Camshaft                             Mk1

651166-14                  Roller — Brake Camshaft                                    Mk1

651166-15                  Roller Pin — Brake Camshaft                                Mk1

651370-1                   Brake Camshaft Rear — RH                                   Mk1

651371-1                   Brake Camshaft Rear — LH                                   Mk1

651777                     Slack Adjuster — Rear                                      Mk1           85.00

651847        4613240080   Footbrake Valve Assembly

651847-1      4613245200   Footbrake Valve

651929-1                   Dustshield Front                                           Mk1

651929-2                   Brake Shoe Return Spring                                   Mk1

652405        KY2498/1     Hand Control Valve                                         Mk1&2         95.00

652406        K2B0528      Spring Brake — Type 24/80

652439        KZ1143/3     Compressor                                                 Mk1

652568                     Slack Adjuster — Rear 8.5m Chassis                         Mk1

652283        269827       Air Dryer — AD2                                            Mk1

653188                     Brake Drum — Rear

653613                     Compressor — Reed Valve                                    All

653613-1                   Cylinder Head Kit — Compressor                             All

653613-3                   Valve Plate Kit — Compressor                               All

653747-1                   Brake Shoe Rear — Lined (exchange unit)                    Mk1

653865       LA8223        Air Dryer                                                  Mk1&2        175.00

653877-1     BR9152        ABS Modulator

653877-6     AE4105        Double Check Valve

653877-8                   ABS Sensor Cable                                                         24.00

653885       AC574         Relay Valve

654466        K2B0521      Spring Brake — Type 30-98

654598        K2B0506      Spring Brake — Type 24/80

654733        KW4455/1     Single Check Valve

654734        295358       Double Check Valve

655201        VPS48HI      Multi Circuit Protection Valve

659372        AC574        Relay Valve
